| 分类 | 硬度 | 精度 | 校正次数 | 偏差 | 材料 | 尺寸(mm) | 参考标准 |
|---|---|---|---|---|---|---|---|
|
HMV( 1,0.1) HMV( 1,0.1) HMV( 1,0.1) HMV (1,0.1,0.01) HMV (0.1,0.01,0.001) |
1600 900, 800, 700, 600, 500, 400, 300 200 (Be Copper) 100 (C2600P), 40(C1020P) 30 (AU) |
±10% ±15 ±15 ±10 ±10 |
4 (2X2) 6 (3x2) 6 (3x2) 6 (3x2) 6 (3x2) |
2% (HV1) 5% (HV0.1) 5% (HV0.1) 7 (100HV0.1),4 (40HV0.1) 4 (HV0.1) |
Si3 N4 SK85 C1720P ← Au |
口10x5 Φ25x6 Φ25x5(2) Φ25x5※ Φ25x5(0.8) |
JSB B 7735 JSB B 7735 JSB B 7735 JSB B 7735 JSB B 7735 |
|
UMV (0.01,0.002) UMV (0.01,0,002) |
900,700,500 (经9.8mN测试) 200 (经9.8mN测试 ） |
±20% ±20% |
6 (3x2) 6 (3x2) |
10% (HV0.01) |
SK85 C172P |
Φ25x6 Φ25x6(2) |
JIS B 7735 JIS B 7735 |
|
★HN-W纳米压痕 约400HV (HV0.01, 0.001 经9.8mN测试) |
6 (3x2 HV, 纳米) | 钨钢单结晶 |
Φ25x6 (W:Φ9x6) |
JIS B 7735 | |||
|
HV(30,1) HV(10,1) HV(10,1) |
1000 (SK120), 900, 800, 700 600, 500, 400, 300, 200, 150, 100 40 |
±15 ±15 ±10 |
10 (5x2)/HV30, 10 6 (3x2)/HV1 |
1.5% 1.5% (150HV和 2.2%以下) |
SK85 SK85 C1020P |
Φ64x15 Φ64x15 Φ64x10 |
JIS B 7735 JIS B 7735 JIS B 7735 |
|
HS HS |
100 (SK120), 95, 90, 80, 70, 60, 50, 40,30 20 (S20C), 7 (C1020P φ64X10) |
±2 ±2 |
HV10 (5x2) HS10 (5x2) |
VHS≤1.5(70HS和1.2%以下) ⊿HS(HS-VHS)≤0.5 |
SK85 ← |
Φ64x15 Φ64x15 |
JIS B 7731 JIS B 7731 |
|
HL HL |
HLE (Dia) 850, 800, 700, 600, 500 HLD (WC) 880, 830, 730, 630, 520 |
±15 ±15 |
(HV校正) |
SK85 SK85 |
Φ115x33 Φ115x33 |
JIS B 7731 相关 |
|
|
HR C HR C HR A HR30N HR15N(45N) |
70 (SK120) ,67, 64, 62, 60 57, 55, 50, 45, 40, 35, 30, 25, 20, 10 87, 85, 83, 81, 78, 75, 71, 65,56 83, 81, 78, 73, 67, 60, 55, 50, 41 92, 90, 87, 85, 80, 75 (43) (23) |
±1 ±1 ±1 ±1 ±1 |
10 (5x2) 10 (5x2) 10 (5x2) 10 (5x2) 10 (5x2) |
0.2 (40HRC和0.3%以下) 0.3 0.6 0.6 |
SKS3 SK85 同HRC 同HRC 同HRC |
Φ64x15 Φ64x15 Φ64x15 Φ64x15 Φ64x15 |
JIS B 7730 JIS B 7730 JIS B 7730 JIS B 7730 JIS B 7730 |
|
HRB W HRB W HRB W HR30T W HR30T W HR15T W HR15T W HR(E·M·L·R·F·S)W HR(E·M·L·R·F·S)W |
100, 95, 90 82, 72 62, 52, 42, 32 78, 72 62, 52, 42, 38, 32 87 82, 78 HRE90 HRM107 HRL118 HRR123 HRF90 HRM67 HRL92 HRR105 HRS90 |
±2 ±2 ±2 ±2 ±2 ±2 ±2 ±2 ±2 |
10 (5x2) 10 (5x2) 10 (5x2) 10 (5x2) 10 (5x2) 10 (5x2) 10 (5x2) 10 (5x2) 10 (5x2) |
0.8 0.8 (50HRB和1%以下) 1.0 1.0 1.0 1.0 1.0
|
SK85 其它钢 C2600P 其它钢 C2600P S35C C2600P (100HV) (40HV) |
Φ64x10 Φ64x15 Φ64x10 Φ64x15 Φ64x10 Φ64x15 Φ64x10 Φ64x10 Φ64x10 |
JIS B 7730 JIS B 7730 JIS B 7730 JIS B 7730 JIS B 7730 JIS B 7730 JIS B 7730 JIS K 7202 JIS K 7202 |
|
HBW(10/3000) HBW(10/3000) |
600, 550, 500, 450, 400, 350 300, 250, 229(d=4mm), 200, 180 HBW( 10/3000)150, HBW(10/500)125 HBW(10/500)100 |
±15 ±15 ±15 ±15 |
6 (3x2) 6 (3x2) 6 (3x2) 6 (3x2) |
1.5% 1.5% 2.5% 3% |
SK85 SK85 S45C S10C |
Φ115x18 Φ115x18 Φ115x18 Φ115x18 |
JIS B 7736 JIS B 7736 JIS B 7736 JIS B 7736 |
